Union Special BC211UA26-1MZ4061
Automatic High Performance Bag Closing Machine with or without Crepe Tape, with Needle Cooler
High Performance two thread double locked chainstitch bag closing machine, automatic version with vertical acting presser foot system for closing filled bags with or without a crepe paper tape. Guides for filler cord for sealing the needle punctures. Without tape folder. For application with bag feed-in device. Independently adjustable chaining and presser foot pressure for optimized bag feeding. Low thread tension reduces the risk of thread breakage. Internal forced lubrication, shell design casting with large external oil filter. Low noise and vibration. Easy and quick sewing speed adjustment. With built-in needle cooler pipe.
| Type No. | BC211UA26-1MZ4061 |
|---|---|
| Series | BC200 |
| Application | Säcke zunähen |
| Stitches/min. | 2.750 |
| Stitch range | 6.50mm – 12.50mm |
| Standard setting | 8.00mm |
| Capacity under presser foot | 12.70mm |
| Thread chain and tape cutter | Electropneumatically guillotine (double acting air cylinder) |
| Handling | Stationary |
| Corrosion protection | Rostgeschützt |
| Class | Hochleistung |
| Sewing capacity on paper | 32 plies |
| Bag material | PP woven-fabric PP laminated woven fabric PE-material Paper |
| Bag feed-in | Automatische Zuführung |
| Lubrication | Forced lubrication |
| Protection classes | Protection class III |
| Standard needle | 9848GF250/100 |
| Start-stop | Automatically by feeler controlled proximity switch |
| Stitch types | 401 |
| Feed type | Bottom feed |
| Closures | Plain closure Crepe tape closure |
| Voltage | 24V DC |
| Color | White |
| Packing mass (L/W/H) | 66cm/45cm/50cm |
| Net weight | 46kg |
| Gross weight | 51kg |
