Union Special 80800LG
Standard Bag Closing Machine Suspended on Top Lock Balancer
Standard one needle two thread double locked bag closing machine suspended from the ceiling, for closing filled bags. Mechanically driven thread chain cutter.
Machine consists of: Top lock balancer with motor 220-240 V/380-420 V, 50Hz three phase, thread stand for two thread cones, built on control box, push button switch for start/stop.
Top lock balancer for weightless suspension.
| Type No. | 80800LG |
|---|---|
| Series | 80800 |
| Application | Säcke zunähen |
| Stitches/min. | 1.250 |
| Stitch range | 6.50mm – 11.00mm |
| Standard setting | 8.00mm |
| Capacity under presser foot | 16.00mm |
| Thread chain and tape cutter | Continuously driven nibbler knive |
| Handling | Suspended |
| Class | Standard |
| Sewing capacity on paper | 32 plies |
| Bag material | Jute PP woven-fabric PP laminated woven fabric PE-material Burlap bag Paper |
| Lubrication | Manual lubrication |
| Standard needle | 9848G250/100 |
| Start-stop | Hand switch |
| Stitch types | 401 |
| Feed type | Bottom feed |
| Closures | Plain closure Fold over closure Closure with filler-cord |
| Color | Olivegreen |
| Packing mass (L/W/H) | 53cm/45cm/72cm |
| Net weight | 67kg |
| Gross weight | 74kg |
