Single Needle Single Thread Overedging Machine with Lower Feed and Edge Trimmer for Butted Joining of Wet Fabrics for Dyeing and Finishing Purposes
Single needle overedging machine with cam controlled lower feed and edge trimmer for butted joining of fabrics for dyeing and finishing purposes, etc. with an approx. 9.5 mm wide single thread overegde seam, seam width unfolded approx. 18 mm. Unpainted parts are chromium plated for protection against rust.
| Type No. | 39500QPZ3110C |
|---|---|
| Series | 39500 |
| Application | Finishing sewing |
| Stitches/min. | 5.000 |
| Stitch range | 2.10mm – 5.00mm |
| Standard setting | 3.20mm |
| Capacity under presser foot | 2.50mm |
| Thread chain and tape cutter | (Ohne) |
| Lubrication | Central lubrication |
| Standard needle | 154GAS100/040 |
| Stitch types | 501 |
| Feed type | Bottom feed |
| Closures | Abutted joining |
| Needles | 1 |
| Installation | Moveable carrier Table assembly |
| Color | Olivegreen |
| Packing mass (L/W/H) | 34cm/40cm/58cm |
| Net weight | 21kg |
| Gross weight | 24kg |
